Radial Engineering BigShot ABY


Expected in 18 days

Radial Engineering BigShot ABY makes it easy to run two amps on stage, without introducing noise or altering your tone.

The pedal has two latching footswitches that allow you to choose which amp is active, or run through both simultaneously. The second amp output features a ground lift and an isolation transformer that can be engaged to eliminate buzz and hum from ground loops, while a 180° polarity reverse switch ensures both amps play back in phase to avoid frequency cancellation.

When powered by an external 9V supply or pedalboard power brick, LEDs provide instant on-stage visual feedback – when power is unavailable, the passive audio circuit still works unaffected.

Best of all, the BigShot ABY is true-bypass device, without any tone-altering buffers between the guitar and the amplifier to ensure you retain the pure tone of your instrument.

Radial Engineering BigShot ABY demo video

Available on backorder



  • Effect: ABY Switcher
  • Design: Analog
  • Mono/Stereo:  Input, Out A, Out B, Tuner
  • Knobs:
  • Switches: Gnd, Pol, ISO, Both Toggle
  • Bypass Mode: True Bypass
  • Power Supply: 9V DC, center negative
  • Power Consumption: NA (only for Leds)
  • Works on batteries: No
  • Format: Normal
  • Made in: USA

Additional information

Weight 0,57 kg
Dimensions 9,1 × 9,9 × 5,1 cm



Radial Engineering






Mono In / Mono Out
