Meris LVX Modular Delay System


In stock

Meris LVX Modular Delay System is a pro audio, modular delay system with a true stereo 60 second looper and high performance signal path. The pedal features configurable delay structures, types, and processing elements for the ultimate customization in delay processing.

The pedal has 2540 ms of highly configurable dual delay and an intuitive color screen-based user interface. A total of 99 preset locations in 33 banks are available. With the favorite preset bank you have instant access to 3 favorite presets. It has a built-in instant access tuner with configurable reference and output mode.

The LVX has a deep modifier section which allows routing of control signals to processing parameters. The true stereo processing elements has completely new designs and known elements from the Meris family (Polymoon, Hedra, Enzo, and Ottobit Jr.). You have selectable note divisions for each side of the stereo dual delay at your disposal and a digitally controlled analog mix bus. The pedal has switchable input / output headroom levels for instrument or synthesizer / line levels and assignable expression pedal control for multiple parameters simultaneously.

The pedal has MIDI and can send and receive MIDI presets and has  beat clock synchronization. You can choose between true bypass (relay) or analog buffered bypass.

Meris LVX Modular Delay System demo video

In stock

SKU: 850015619069 Categories: ,


  • Effect: Delay/looper
  • Design: Digital
  • Mono/Stereo: L + R In, L+R Out, Exp, Midi In. Midi Out, USB C
  • Knobs: Time, Feedback, Mod, Mix, Controller 1 + 2, Preset
  • Switches: Rec/Overdub, Play/Stop, Loop FX1, Loop FX2
  • Bypass Mode: True/Buffered Bypass
  • Power Supply: 9V DC, center negative
  • Power Consumption: 300 mA
  • Works on batteries: No
  • Format: Normaal
  • Made in: USA

Additional information

Weight 0,68 kg
Dimensions 18,4 × 11,4 × 5,1 cm







Delay, Looper


Stereo In / Stereo Out
